text-to-reality

io.github.ai-wesv0.1.1Updated Oct 7, 2026

Turn an idea into a device anyone can build: parts, printed parts, wiring, code and a picture guide.

VerifiedSTDIODesktop onlyDeveloper ToolsMedia & Design

Overview

AI-generated overview

Turns a described idea into a build package for a physical device: parts list, printable parts, wiring, code, and a picture guide.

What it does
The local server gives an agent tools to create build projects and fill in seven stages: requirements, parts list, 3D-printable parts, wiring, firmware code, assembly guide, and tests. It records files, detects files edited after they were checked, validates the package, keeps a build history, and looks up board pin layouts and plug-on connectors. Each build is a plain folder the user owns.
When to use it
Use it when you want an assistant to plan a small electronics device end to end, from a plain-language description to an orderable parts list, printable case, wiring plan, firmware, and step-by-step picture guide. It suits people without electronics experience who want a package someone else can assemble.
Requirements
Runs locally over stdio as a PyPI package launched with uvx, so uv must be installed. No account or API key is declared. Projects are saved in a folder chosen by the TEXT_TO_REALITY_DIR environment variable, defaulting to a text-to-reality folder under the app's working directory. Desktop only.
Before you install
It writes project folders and files on your machine, so point TEXT_TO_REALITY_DIR at a location you are willing to have written to. The generated parts list and connector recommendations may lead you to buy hardware from third-party sellers; review the package before ordering or building. No credentials are requested.

Installation

In SourceWeft

  1. Open text-to-reality in the dashboard and add it to a workspace.
  2. Enable the server for the chats that should use its tools.

Desktop only via STDIO. STDIO servers start a local process, so they need the SourceWeft desktop host.

Other MCP clients

Follow the launch instructions in the repository.

README

text-to-reality

Give your agent the power to build real things.

text-to-cad makes a part. text-to-reality makes the working device.

[License: MIT] [PyPI] [Python]

Describe something you want to exist. Your agent turns it into a build package anyone can put together by following pictures:

  • a parts list you can order, using parts that plug together
  • 3D-printable parts for the case and mounts
  • the wiring, every wire and which connector it goes in
  • the code, ready to load
  • a step-by-step picture guide written for someone who has never built electronics
  • tests, so you know it works

No soldering, no breadboard, no electronics experience required. It runs on your machine: no account, no API key, and your projects are plain folders you own.

Example: Agent Meter

"Build me a little desk character that shows what my coding agent is doing and how much of my Claude allowance is left."

[Agent Meter, a small printed robot character with a screen in its head (concept render)]

Agent Meter illustrates this workflow: a Seeed Studio XIAO ESP32-S3 and a small screen inside a printed character, wired with plug-on connectors, with firmware and a picture guide. Its face shows when your agent is working, finished or waiting on you, plus your remaining allowance.

Get the Agent Meter kit →

Install

Ask your agent

text
Install text-to-reality from https://github.com/ai-wes/text-to-reality

Or install it yourself. text-to-reality runs through uv: check it's installed with uv --version, or use uv's installer. Then run the commands for your agent and restart it.

Claude Code

bash
claude plugin marketplace add ai-wes/text-to-realityclaude plugin install text-to-reality@ai-wes

To update: claude plugin marketplace update ai-wes, then claude plugin update text-to-reality@ai-wes.

Codex

bash
codex plugin marketplace add ai-wes/text-to-realitycodex plugin add text-to-reality@ai-wes

Cursor

Cursor also loads the Claude Code plugin; if that's installed, skip this.

bash
git clone --depth 1 https://github.com/ai-wes/text-to-reality ~/.cursor/plugins/local/text-to-reality

Claude Desktop

Add the server to Claude Desktop's config (Settings > Developer > Edit Config), then restart. If it can't find uvx, use its full path (which uvx).

json
{  "mcpServers": {    "text-to-reality": {      "command": "uvx",      "args": ["--no-config", "--managed-python", "--python", "3.13", "--from", "text-to-reality==0.1.1", "text-to-reality", "mcp"]    }  }}

Projects are saved in text-to-reality/ in the folder the app starts in; set TEXT_TO_REALITY_DIR in env to choose another folder.

Other agents

bash
npx skills add ai-wes/text-to-reality

Then add the MCP server above to your agent's MCP config.

Works with text-to-cad

text-to-reality plans the whole device; text-to-cad is great at the printed parts. Install both, and the agent uses text-to-cad for the printed parts when it's available.

How it works

Each build is a folder. The agent fills in seven stages and checks them:

StageWhat's in it
Requirementsbrief.md: what it does, size, power, budget, how you'll know it works
Partsbom.json: every part and quantity
Printed partsCAD source and STL/3MF files
Electronicswiring.json: every wire, its color, and its connector
Codefirmware source and how to load it
Assemblythe picture guide
Testingwhat to check, and what a pass looks like

The local MCP server gives the agent tools to create projects, record files, catch files edited after they were checked, validate the package, keep a build history, and look up board header layouts and plug-on parts.

You can also check a folder yourself:

bash
uvx text-to-reality check ./text-to-reality/my-build

Parts that plug together

Loose jumper wires fall off and get swapped. JIG_ makes connectors that turn the wires going to one row of pins into a single plug, so wiring becomes plugging things in.

The agent uses JIG_ connectors by default. It looks up each board's pin rows, picks one connector per row, lists what to buy, and notes any row a connector can't fit. Get them at jig-robotics.com →

Each connector is a base that holds the wires in order and a cover that snaps on. The picture guide shows how to load it, close it and plug it on.

License

MIT

Source: README.md at commit 68191fb

Tools

0
Tool metadata has not been indexed yet.

Version history

1
  1. v0.1.1LatestOct 7, 2026
